Musktool-Hybrid Solar Inverter 3kw 4kw 6kw 8kw 10kw Invert Grid Solar System on Grid Inverter 230V Pure Sine Wave

2025-08-04 15:45:19

Main Feature : Musktool-Hybrid Solar Inverter 3kw 4kw 6kw 8kw 10kw Invert Grid Solar System on Grid Inverter 230V Pure Sine Wave
Serial No. : Owen0261

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Features

Multi - power Coverage and High - efficiency Energy Conversion

This series of inverters offers power options from 3kW to 10kW, meeting the needs of residential, small - and medium - sized commercial, and industrial scenarios.
Its pure sine wave output (total harmonic distortion < 3%) can stably drive inductive loads such as air conditioners and refrigerators, while protecting sensitive electronic devices like computers and medical equipment.
By adopting dual MPPT (Maximum Power Point Tracking) technology, a single device can be connected to two sets of photovoltaic arrays.
The MPPT voltage range is as wide as 120 - 500V DC, adapting to different combinations of photovoltaic panels under various lighting conditions and improving power generation efficiency (for example, the power generation in cloudy weather is 15% higher than that of the traditional single - MPPT scheme).

Hybrid Mode and Intelligent Energy Management</b> Multi - energy Synergy:

It supports the hybrid power supply mode of photovoltaic + grid + energy - storage battery, and can automatically optimize energy distribution.
For example, it preferentially uses photovoltaic power, and stores the remaining power in the battery.
When the grid power fails, it seamlessly switches to battery power supply (switching time < 10ms) to ensure the continuous operation of critical loads.

NUK-HFP		HFP33224	HFP43224	HFP63248	HFP83248	HFP103248	HFP123248
PV	Max PV Input Power	5000W		7000W	4500W*2	6000W*2
	PV Voltage（V）	40VDC-500VDC		80VDC-500VDC
	Rated Power (W)	3.3KW 24VDC	4.3KW 24VDC	6.3KW 48VDC	8.3KW 48VDC	10.3KW 48VDC	12.3KW 48VDC
	Solar Charge Controller Charging Current (A)	120A	150A	120A	150A	180A	200A
	AC Charging Current (A)	80A	100A	80A	100A	120A	140A
	Number Of Mppt Solar Charge Controllers	1 Routed			2 Routed

Place of Origin	China
Brand Name	MEWOI
Model Number	MEWOI
AC Charging Current (A)	80A
Output Voltage	220V
Solar Charge Controller Charging Current (A)	120A
Output Frequency	50Hz
Output Type	Single
Type	DC/AC Inverters
Inverter Efficiency	3300W/4300W/6300W/8300W/10.3KW/12.3KW
Certificate	CE
Warranty	1 Years
Product name	Off-grid Hybrid Inverter
Application	Solar Power System Home
Inverter type	Hybrid Grid Inverter
Keyword	Solar Energy Power Inverter
Display	LCD Display
Waveform	Pure Sin Wave

Lable: Musktool-Hybrid Solar Inverter 3kw 4kw 6kw 8kw 10kw Invert Grid Solar System on Grid Inverter 230V Pure Sine Wave
