Musktool-FST600-400 High-precision Online Infrared Temperature Sensor
【Product description】
| FST600-400 infrared temperature sensor is a device that uses infrared to measure temperature. It can calculate the surface temperature of an object by measuring the intensity of infrared radiation emitted by the target without touching the target. Products are widely used in power equipment, metallurgy, construction industry, chemical products and chemical industry and its automation control and detection systems. |
【Technical Parameters】
Measuring range -70~380℃ Temperature measurement accuracy ±2% of measured value or ±2℃, whichever is greater Repeatability ±1% of measured value or ±1℃, whichever is greater Signal output 4~20mA、RS485 Supply voltage 10~30VDC、5~30VDC(RS485) Optical resolution 10:01 Firing rate 1 Response time 300 ms Response wavelength 8-14um Ambient temperature -40~85℃ Storage temperature -40~85℃ Relative humidity 10~95% (no condensation) Outer shell 304 stainless steel Size 119mm×ф18.7mm (length * diameter) Electrical connections Direct out Protection level IP65
【Scope of application】
| ♦ Power equipment, medical field ♦ Food construction industry, chemical products and chemical industry ♦ Temperature monitoring in process and production areas ♦ Metallurgy, petrochemical, electric power, light industry, textile industry, food industry, national defense and scientific research |
【Product size and wiring method】
